10 Pack General Purpose Relay, RGF2BD524L, 25A 24VAC Coil Voltage, 6Pin Double Pole Single Throw Normally Open Contacts, with LED Indicator Light and Protection Cover, 35mm DIN Rail Mount
Product details
| Management number | 211059553 | Release Date | 2026/04/04 | List Price | $39.60 | Model Number | 211059553 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Parameter】 Coil Voltage: AC 24V; Resistive Load: 25A 277VAC/30VDC; Contact: DPST - 2NO; Number of Pins: 6
- 【Certification】UL, TÜV, CE, ROHS Certified for Quality Assurance
- 【Bridge Contacts】The RGF series relays employ a unique "double-break" contact structure, capable of simultaneously connecting or disconnecting two circuits, they possess higher breaking capacity and arc-extinguishing performance, making them suitable for applications requiring frequent switching
- 【Superior Quality】This relay shell is made of flame retardant material, with high strength, high temperature resistance, corrosion resistance and more safety . Standard turns and electromagnetic copper coil make the Pick-up more reliable and enduring, Long service life, up to 50 million cycles or more
- 【Widely Used】Bridge-type contact relays, due to their high reliability and long lifespan, are commonly used in demanding applications such as industrial automation and control equipment, power system protection and control, and loads with frequent switching. They are widely used in high-load circuits such as air conditioners and refrigerators
| Model | RGF2BD524L |
|---|---|
| Brand Name | Weasch |
| Part Number | RGF2BD524L |
| Contact Type | Normally Open |
| Manufacturer | Weasch |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 25 Amps |
| Contact Material | Silver Copper |
| Specification Met | CE, EAC, TUV, UKCA, cULus |
| Included Components | RGF2BD524L |
