4K 3x3 HDMI New Video Wall Controller HDMI 1.4, HDCP1.4 Compliant | 1 HDMI/DVI Input 9 HDMI OutputTV Video Processor Splicer 1x2 1x3 1x4 2x1 2x2 2x4 3x1 3x2 4x1 4x2 Upgrade with RS232 Control

Port Specifications : HDMI Port 1*HDMI INPUT 9*HDMI OUPUT Interface Type: HDMI-A Socket Signal Standard: HDMI1.4 Backward compatible; Resolution: VESA Standard, ≤3840×2160p@30Hz; DVI Port 1*DVI INPUT Interface Type: DVI-I Socket Signal Standard: DVI1.0，HDMI1.4 Backward compatible; Resolution: VESA Standard, ≤3840×2160p@30Hz; AUDIO OUT Audio Output Interface, Dual Track; General Specifications Power Supply Internal 100～240V AC, 50～60Hz ; Temperature Storage: T: -40˚C ~ +80 ˚C 、 H: 10% ~ 90%, Non-condensing; Working: T: 0 ˚C ~ +60 ˚C 、 H: 10% ~ 90%, Non-condensing; Machine Size 370mm (Length) x 155 mm (Width) x 35mm (Height) Including Ear Hook Packing Size 420mm (Length) x 220 mm (Width) x 85mm (Height) Product Weight Gross Weight : 2.0Kg ; Package Weight Volume Weight : 2.5Kg ; Warranty 1 Year; Note: All Rated Voltages Are On Average ±10%; Packing List : 4K HDMI 3x3 Video Wall Controller* 1 ; Remote * 1 ; Power Cable * 1 ; Remote Antenna * 1 ; Certificate * 1 ; Warranty Card * 1 ;

• 🌟 3*3 video wall controller, also is a 4K HDMI Splicer. uses 1 HDMI and 1 DVI video input, Can through the key or remote to selection the current input, have 9 channel of HDMI output, Support 4K and HDCP;
• 🌟 Support Remote Control -- 2.4G RF remote control is adopted, has long remote control distance and strong penetration ability;
• 🌟 Support One Key Black & One Key Freeze -- When the image output needs to be closed during the performance, the black screen key can be used to realize fast black screen. During playback, it may be necessary to freeze the current picture to realize "pause" picture;
• 🌟 Support Screen Rotation -- In order to meet more splicing requirements, the spliced output image can be rotated 180 degrees;
• 🌟 Support Brightness Adjustment -- Support 32 levels of brightness adjustment by the remote control, and the default value is 25 level;
• 🌟 Support Audio Sync Output -- HDMI audio and vide can be synchronized output. And the audio output port is a independent interface
