Winters 2-1/2" Dial Size, Liquid Filled Pressure Gauge, Potable Brass Internals, 304 Stainless Steel Case, Dual Scale 0-60 psi/kPa, 1.5% Acc, 1/4" NPT Bottom Mount, Drinking Water Pressure Gauge
Product details
| Management number | 211720534 | Release Date | 2026/04/04 | List Price | $13.68 | Model Number | 211720534 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Applications: Ideal for plumbing, heating, air conditioning, pumps, compressors and pneumatic equipment. Pulsation resistant, liquid filled stainless steel case. CRN registered. Dial: White aluminum with black and red markings. Lens: Polycarbonate. Fill Fluid: Glycerin. Case: 304 SS. Socket: Lead Free Brass. Bourdon Tube: Lead free phosphor bronze C or coil shaped. Movement: Brass. Socket Gasket: Buna N for two-piece internal socket seal. Working Pressure: Maximum 75% of full scale value. Over Pressure Limit: 25%. Ambient Temperature: -4°F to 150°F (-20°C to 65°C). Dial Size: 2.5” (63mm). Connection: 1/4” NPT Bottom connect with restricted orifice. Accuracy: 1.5% of Full Scale Value. Range: 0-60 PSI/KPA
- Pulsation resistant, glycerin filled stainless steel case
- Lead free wetted parts
- ±1.5% accuracy
- Restricted orifice
- Crimp-On bezel
| UPC | 628311266108 |
|---|---|
| Brand Name | Winters Instruments |
| Unit Count | 1 Count |
| Item Weight | 0.35 Pounds |
| Manufacturer | Winters |
| Material Type | Stainless Steel |
| Item Dimensions | 3 x 4 x 2 inches |
| Included Components | Unit and Instruction Guide |
| Global Trade Identification Number | 00628311266108 |
